Overview

MetalPipe is a package of classes and functions that help you write consistent, efficient, configuration-driven ETL pipelines in Python. It is open-source and as simple as possible (but not simpler).

This overview tells you why MetalPipe exists, and how it can help you escape from ETL hell.

Why is it?

Tolstoy said that every happy family is the same, but every unhappy family is unhappy in its own way. ETL pipelines are unhappy families.

Why are they so unhappy? Every engineer who does more than one project involving ETL eventually goes through the same stages of ETL grief. First, they think it’s not so bad. Then they do another project and discover that they have to rewrite very similar code. Then they think, “Surely, I could have just written a few library functions and reused that code, saving lots of time.” But when they try to do this, they discover that although their ETL projects are very similar, they are just different enough that their code isn’t reusable. So they resign themselves to rewriting code over and over again. The code is unreliable, difficult to maintain, and usually poorly tested and documented because it’s such a pain to write in the first place. The task of writing ETL pipelines is so lousy that engineering best practices tend to go out the window because the engineer has better things to do.

What is it?

MetalPipe is an ETL framework for the real world. It aims to provide structure and consistency to your ETL pipelines, while still allowing you to write bespoke code for all of the weird little idiosyncratic features of your data. It is opinionated without being bossy.

The overall idea of MetalPipe is simple. On the surface, it looks a lot like streaming frameworks such as Spark or Storm. You hook up various tasks in a directed graph called a “pipeline”. The pipeline ingests data from or more places, transforms it, and loads the data somewhere else. But it differs from Spark-like systems in important ways:

1. It is agnostic between stream and batch. Batches of data can be turned into streams and vice-versa.
2. It is lightweight, requiring no specialized infrastructure or network configuration.
3. Its built-in functionality is specifically designed for ETL tasks.
4. It is meant to accommodate 90% of your ETL needs entirely by writing configuration files.

What isn’t it?

There are many things that MetalPipe is not:

1. It is not a Big Data(tm) tool. If you’re handling petabytes of data, you do not want to use MetalPipe.
2. It is not suitable for large amounts of computation. If you need to use dataframes to calculate lots of complex statistical information in real-time, this is not the tool for you.

Basically, MetalPipe deliberately makes two trade-offs: (1) it gives up Big Data(tm) for simplicity; and (2) it gives up being a general-purpose analytic tool in favor of being very good at ETL.

MetalPipe pipelines

An ETL pipeline in MetalPipe is a series of nodes connected by queues. Data is generated or processed in each node, and the output is placed on a queue to be picked up by downstream nodes.

Very high-level view of a MetalPipe pipeline

For the sake of convenience, we distinguish between three types of nodes (although there’s no real difference in their use or implementation):

1. Source nodes. These are nodes that generate data and send it to the rest of the pipeline. They might, for example, read data from an external data source such as an API endpoint or a database.
2. Worker nodes. The workers process data by picking up messages from their incoming queues. Their output is placed onto any number of outgoing queues to be further processed by downstream nodes.
3. Sink nodes. These are worker nodes with no outgoing queue. They will typically perform tasks such as inserting data into a database or generating statistics to be sent somewhere outside the pipeline.

All pipelines are implemented in pure Python (version >=3.5). Each node is instantiated from a class that inherits from the MetalNode class. Queues are never instantiated directly by the user; they are created automatically whenever two nodes are linked together.

There is a large (and growing) number of specialized MetalNode subclasses, each geared toward a specific task. Such tasks include:

1. Querying a table in a SQL database and sending the results downstream.
2. Making a request to a REST API, paging through the responses until there are no more results.
3. Ingesting individual messages from an upstream node and batching them together into a single message, or doing the reverse.
4. Reading environment variables.
5. Watching a directory for new files and sending the names of those files down the pipeline when they appear.
6. Filtering messages, letting them through the pipeline only if a particular test is passed.

Somewhat high-level view of a MetalPipe pipeline

All results and messages passed among the nodes must be dictionary-like objects. By default, messages retain any keys and values that were created by upstream nodes.

The goal is for MetalPipe to be “batteries included”, with built-in MetalNode subclasses for every common ETL task. But because ETL pipelines generally have something weird going on somewhere, MetalNode makes it easy to roll your own node classes.

Nodes are defined in code by instantiating classes that inherit from MetalNode. Upon instantiation, the constructor takes the same set of keyword arguments as you see in the configuration. Nodes are linked together by the > operator, as in node_1 > node_2. After the pipeline has been built in this way, it is started by calling node.global_start() on any of the nodes in the pipeline.

The code corresponding to the configuration file above would look like this:

# Define the nodes using the various subclasses of MetalNode
get_environment_variables =
GetEnvironmentVariables(
    environment_variables=['API_KEY', 'API_USER_ID'])
print_variables = PrinterOfThings(prepend='Environment variables: ')

# The '>' operator can also be chained, as in:
# node_1 > node_2 > node_3 > ...
get_environment_variables > print_variables

# Run the pipeline. This command will not block.
get_environment_variables.global_start()

Rolling your own MetalNode class

If there are no built-in MetalNode classes suitable for your ETL pipeline, it is easy to write your own.

For example, suppose you want to create a source node for your pipeline that simply emits a user-defined string every few seconds forever. The user would be able to specify the string and the number of seconds to pause after each message has been sent. The class could be defined like so:

class FooEmitter(MetalNode):  # inherit from MetalNode
    '''
    Sends ``self.output_string`` every ``self.interval`` seconds.
    '''
    def __init__(self, output_string='', interval=1, **kwargs):
        self.output_string = output_string
        self.interval = interval
        super(FooEmitter, self).__init__()  # Must call the `MetalNode` __init__

    def generator(self):
        while True:
            time.sleep(self.interval)
            yield self.output_string  # Output must be yielded, not returned

Let’s look at each part of this class.

The first thing to note is that the class inherits from MetalNode – this is the mix-in class that gives the node all of its functionality within the MetalPipe framework.

The __init__ method should take only keyword arguments, not positional arguments. This restriction is to guarantee that the configuration files have names for any options that are specified in the pipeline. In the __init__ function, you should also be sure to accept **kwargs, because options that are common to all MetalNode objects are expected to be there.

After any attributes have been defined, the __init__ method must invoke the parent class’s constructor through the use of the super function. Be sure to pass the **kwargs argument into the function as shown in the example.

If the node class is intended to be used as a source node, then you need to define a generator method. This method can be virtually anything, so long as it sends its output via a yield statement.

If you need to define a worker node (that is, a node that accepts input from a queue), you will provide a process_item method instead of a generator. But the structure of that method is the same, with the single exception that you will have access to a __message__ attribute which contains the incoming message data. The structure of a typical process_item method is shown in the figure.

A typical process_item method for MetalNode objects

For example, let’s suppose you want to create a node that is passed a string as a message, and returns True if the message has an even number of characters, False otherwise. The class definition would look like this:

class MessageLengthTester(MetalNode):
    def __init__(self):
        # No particular initialization required in this example
        super(MessageLengthTester, self).__init__()

    def process_item(self):
        if len(self.__message__) % 2 == 0:
            yield True
        else:
            yield False

Composing and configuring MetalNode objects

Warning

The code described in this section is experimental and very unstable. It would be bad to use it for anything important.

Let’s suppose you’ve worked very hard to create the pipeline from the last example. Now, your boss says that another engineering team wants to use it, but they want to rename parameters and “freeze” the values of certain other parameters to specific values. Once that’s done, they want to use it as just one part of a more complicated MetalPipe pipeline.

This can be accomplished using a configuration file. When MetalPipe parses the configuration file, it will dynamically create the desired class, which can be instantiated and used as if it were a single node in another pipeline.

The configuration file is written in YAML, and it would look like this:

name: FooMessageTester

nodes:
  - name: foo_generator
    class FooEmitter
    frozen_arguments:
      message: foobar
    arg_mapping:
      interval: foo_interval
  - name: length_tester
    class: MessageLengthTester
    arg_mapping: null

With this file saved as (e.g.) foo_message.yaml, the following code will create a FooMessageTester class and instantiate it:

foo_message_config = yaml.load(open('./foo_message.yaml', 'r').read())
class_factory(foo_message_config)
# At this point, there is now a `FooMessageTester` class
foo_node = FooMessageTester(foo_interval=1)

You can now use foo_node just as you would any other node. So in order to run it, you just do:

foo_node.global_start()

Because foo_node is just another node, you can insert it into a larger pipeline and reuse it. For example, suppose that other engineering team wants to add a PrinterOfThings to the end of the pipeline. They’d do this:

printer = PrinterOfThings()
foo_node > printer
